Hakan Nickel Alloys, located in Istanbul, Turkey, has built a solid reputation as a reliable manufacturer and supplier of top-notch Inconel Ball Valves. These valves are crafted to meet the highest standards of durability and performance. With a wealth of experience in creating valves that excel in tough environments, the company prioritizes precision engineering, top-quality materials, and rigorous quality control. Inconel Ball Valves are known for their impressive resistance to corrosion, oxidation, and high temperatures, making them ideal for critical industries around the globe. Hakan Nickel Alloys is dedicated to providing innovative, long-lasting, and cost-effective valve solutions that meet a variety of industrial needs while ensuring global competitiveness and reliability.
These Inconel Ball Valves are made from nickel-chromium-based alloys, enhanced with iron, molybdenum, and niobium, which give them remarkable resistance to oxidation and corrosion even at high temperatures. They boast exceptional strength, toughness, and resistance to stress-cracking, even under extreme pressure and thermal cycling. These valves maintain their structural integrity across a broad temperature range, guaranteeing reliable sealing and a long service life. With outstanding mechanical properties like high tensile strength, creep resistance, and hardness, Inconel Ball Valves are designed to thrive in aggressive chemical, marine, and high-temperature industrial settings.
| VALVE SIZE | 6 MM TO 50 MM or 1/8″ TO 2″ |
| SPECIFICATION | ASME B16.34, BS 5352, ASME SA494/ASTM A494 API 602, ASME B16.5, ASME B1.20.1, ASME B16.25, ASME B16.10, ASME B16.11, DIN3352 |
| CONNECTION | TUBE END, WELD NIPPLE,THREADED, SOCKET WELD, BUTT WELD, FLANGED, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 4 WAY, 3 WAY, 2 WAY, 5 WAY, |
| SEAL RING MATERIAL | PVDF, PTFE, PEEK, DELRIN, GRAPHITE |
| PRESSURE RATING | 15000 PSI, 3000 PSI, 1500 PSI, 10000 PSI, 6000 PSI, 20000 PSI |
| GRADE | INCONEL 625, 600, 800, 718, 825, ALLOY 20 |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER , CHEMICAL |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS , |
| BODY TYPE | BAR STOCK |
| MEDIA TEMPERATURE | (-120* C – 500*C ) AS PER PRESSURE RANGE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | Al-Ti | C | Si | S | Fe | Cr2 | Ni | |
| Inconel Ball Valve | min. | – | – | – | – | – | – | 20.0 | 58.0 |
| max. | 0.50 | 0.40 | 0.10 | 0.50 | 0.015 | 5.0 | 23.0 | – | |
| Grade | Strength of Yield 0.2% Proof (MPa) minimum | Elongation (% in 50mm) minimum | Strength of Tensile (MPa) minimum | Hardness | |
| Brinell (HB) maximum | Rockwell B (HR B) maximum | ||||
| Inconel Ball Valve | Psi – 75,000 , MPa – 517 | 42.5 | Psi – 1,35,000 , MPa -930 | – | – |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Ball Valve in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel Ball Valves are extensively utilized in industries where durability and resistance to harsh conditions are crucial. They are commonly found in chemical and petrochemical plants, oil and gas processing, marine engineering, and power generation facilities. Their capability to manage corrosive fluids, aggressive gases, and high-pressure steam makes them essential in refineries and offshore drilling operations. In the aerospace sector, they are used in turbine systems and exhaust equipment due to their remarkable heat resistance. Additionally, these valves play a vital role in nuclear plants, pharmaceutical processing, and desalination units, ensuring safety and efficiency in various applications.
