Hakan Nickel Alloys in Istanbul, Turkey makes Hastelloy Manifold Valves, which are strong valves used to control and direct the flow of liquids or gases in multiple pipes at the same time. These valves are very tough and can handle high heat, pressure, and harsh chemicals without rusting or breaking. Hastelloy Manifold Valves are used in chemical plants, power plants, oil and gas industries, ships, and aerospace. Hakan Nickel Alloys ensures every valve is smooth, precise, and reliable. Engineers can use them safely for long-term, accurate flow control in tough industrial conditions.
Hastelloy Manifold Valves are made mainly of nickel, molybdenum, and iron, with small amounts of chromium and cobalt. This makes them very strong, corrosion-resistant, and heat-resistant. They can handle high temperatures and heavy pressure without bending, cracking, or rusting. The valves remain durable even after long-term use in harsh chemical or industrial environments. These properties make Hastelloy Manifold Valves ideal for controlling and directing liquids or gases safely in chemical plants, power plants, oil and gas industries, ships, and aerospace where ordinary valves would fail.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Needle Valve in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Manifold Valves are used wherever strong, heat-resistant, and corrosion-resistant valves are needed to manage multiple flow lines. Chemical plants use them to control and direct acids, chemicals, and hot liquids safely. Power plants use them in boilers, turbines, and piping systems under high heat and pressure. Oil and gas industries rely on them in pipelines, refineries, and offshore platforms. Ships use them to manage fluid systems exposed to seawater and chemicals. Aerospace industries use them in fuel and high-temperature systems. Hastelloy Manifold Valves are chosen because they are precise, safe, reliable, and long-lasting.
