Hakan Nickel Alloys, a top-notch manufacturer and supplier located in Istanbul, Turkey, specializes in high-quality Hastelloy Ball Valves that are perfect for industrial applications facing high corrosion and extreme temperatures. These valves are celebrated for their outstanding resistance to both oxidizing and reducing environments, ensuring dependable flow control and a tight shut-off even in the toughest conditions. Crafted with precision and rigorous quality checks, Hastelloy Ball Valves from Hakan Nickel Alloys promise exceptional durability, mechanical strength, and a long lifespan, making them a go-to choice for the chemical, petrochemical, marine, and power generation sectors.
Hastelloy Ball Valves are mainly made up of nickel (50–55%), molybdenum (15–18%), and chromium (15–18%), with trace amounts of iron and cobalt to boost their corrosion resistance and mechanical performance. On the mechanical side, they showcase impressive tensile strength ranging from 690 to 950 MPa, along with excellent yield strength and remarkable resistance to fatigue and creep. They also maintain dimensional stability, toughness, and reliable performance across a broad temperature spectrum, including highly corrosive and elevated-temperature settings.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Ball Valves find extensive use in the chemical and petrochemical industries for managing the flow of aggressive and corrosive fluids within piping systems. In marine and offshore settings, they are utilized in seawater systems, desalination plants, and pumps that demand corrosion-resistant and durable valves. The power generation sector employs them in boilers, superheaters, and turbines. Thanks to their unique blend of corrosion resistance, mechanical strength, and thermal stability, Hastelloy Ball Valves are crucial for ensuring safe, reliable, and long-lasting flow control in challenging industrial environments.
