Hakan Nickel Alloys, located in Istanbul, Turkey, is a trusted name in the manufacturing and supply of high-performance Duplex Ball Valves. These valves are specifically designed for tough flow control tasks, boasting remarkable durability, resistance to corrosion, and impressive strength. Hakan Nickel Alloys produces Duplex Ball Valves that adhere to international standards, catering to essential industries such as oil and gas, petrochemical, marine, and desalination. Engineered to withstand high pressure and challenging fluid conditions, these valves guarantee a tight shut-off, minimize wear, and ensure a long lifespan. With a strong focus on quality and reliability, Hakan Nickel Alloys delivers ball valve solutions tailored for extreme service environments around the globe.
Typically crafted from Duplex 2205 stainless steel, Duplex Ball Valves feature a well-balanced microstructure of austenite and ferrite. This alloy comprises about 22% chromium, 5–6% nickel, 3% molybdenum, and nitrogen, providing outstanding mechanical strength (with tensile strength ranging from 620 to 880 MPa) and excellent resistance to corrosion. These valves effectively combat stress corrosion cracking, pitting, and crevice corrosion, especially in chloride-rich settings. The duplex structure enhances fatigue resistance and ensures the material remains stable under varying pressure and temperature conditions. Duplex Ball Valves excel in maintaining tight sealing performance, are dimensionally stable, and offer dependable operation in both high-pressure and highly corrosive fluid systems.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | UTS (MPa) | % Elongation | Hardness(BHN) | YS (MPa) |
| 31803 | 620 min. | 25 min. | 293 max. | 450 min. |
| 2205 | 655 min. | 25 min. | 293 max. | 450 min. |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Ball Valve in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Ball Valves are perfect for managing fluid flow in challenging environments like offshore platforms, chemical processing facilities, desalination plants, and marine pipelines. In the oil and gas industry, they play a crucial role in topside and subsea systems that handle corrosive fluids under high pressure. Their exceptional corrosion resistance makes them a reliable choice for these demanding applications.
