Hakan Nickel Alloys, located in Istanbul, Turkey, is a reputable manufacturer and supplier of **Super Duplex Steel Stud Bolts S32760**. These bolts are celebrated for their remarkable strength, durability, and ability to withstand harsh environments. With a strong focus on high-quality engineering, the company ensures that their stud bolts meet international standards for critical applications across various industries, including oil and gas, petrochemicals, marine, and chemical processing. Designed to perform exceptionally well under extreme pressure and temperature, these bolts are a reliable choice for demanding projects where safety, longevity, and resistance to corrosion are crucial.
Super Duplex Steel Stud Bolts S32760 are made from a blend of chromium, nickel, molybdenum, and nitrogen, which provides outstanding resistance to chloride-induced stress corrosion cracking and pitting. They boast impressive mechanical properties, such as high tensile and yield strength, along with good ductility and toughness. Their unique dual-phase microstructure, consisting of austenite and ferrite, enhances fatigue resistance and ensures they remain durable in aggressive environments. These characteristics make them highly effective against corrosion, erosion, and mechanical wear, making them ideal for critical fastening applications in marine, offshore, and chemical sectors.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32760 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Stud Bolts S32760 in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Super Duplex Steel Stud Bolts S32760 are extensively utilized in industries that require high strength and exceptional corrosion resistance. They play a vital role in offshore platforms, subsea equipment, and marine engineering, where they endure exposure to seawater. In the oil, gas, and petrochemical sectors, these bolts are commonly found in pressure vessels, heat exchangers, and process piping systems. Moreover, they are also used in desalination plants, chemical processing units, and power generation systems, providing durability and reliability in highly corrosive and high-stress environments, ensuring long-term performance and safety in challenging operational conditions.
