Hakan Nickel Alloys, based in Istanbul, Turkey, is a trusted manufacturer and supplier of Rene 41 Foils, engineered for high-temperature and high-strength applications. Known for their reliability and superior performance, these foils are precision-rolled to ensure consistent thickness, excellent surface finish, and dimensional accuracy. Rene 41 Foils are widely used in aerospace, turbine, and power generation industries where durability under extreme conditions is critical. At Hakan Nickel Alloys, we combine advanced manufacturing processes with strict quality control to deliver foils that meet international standards, offering engineers and designers dependable solutions for demanding, high-performance applications.
Rene 41 Foils are composed primarily of nickel, cobalt, chromium, molybdenum, titanium, and aluminum, forming a precipitation-hardenable superalloy. This composition gives them outstanding high-temperature strength, excellent creep and fatigue resistance, and remarkable dimensional stability. The foils maintain mechanical integrity under extreme heat and stress, making them ideal for applications in gas turbines, aerospace engines, and other high-performance components. Lightweight yet robust, Rene 41 Foils offer superior corrosion and oxidation resistance, ensuring long-term durability and reliable performance in demanding environments.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
Rene 41 Foils are extensively used in industries requiring high-temperature strength and stability. In aerospace, they are employed in turbine blades, engine components, and exhaust systems that must withstand extreme heat and stress. Power generation industries use them in gas turbines and high-temperature processing equipment. Chemical and industrial sectors utilize Rene 41 Foils for heat exchangers, furnace parts, and superalloy components exposed to harsh environments. Their combination of high creep resistance, fatigue strength, and oxidation resistance makes Rene 41 Foils a preferred choice for engineers seeking reliable, long-lasting performance in critical high-temperature applications.
