Hakan Nickel Alloys, a reputable manufacturer and supplier located in Istanbul, Turkey, proudly offers top-notch **Nimonic 90 Sheets and Plates** that adhere to the highest international standards. Renowned for their exceptional strength, resistance to oxidation, and remarkable durability, these sheets and plates are a go-to choice in industries that demand materials capable of enduring extreme temperatures. With state-of-the-art production facilities and rigorous quality control, Hakan Nickel Alloys guarantees products that boast precision, reliability, and a long lifespan. The company caters to a variety of sectors, including aerospace, power generation, chemical processing, and automotive, playing a vital role in advanced engineering applications around the globe.
Nimonic 90 Sheets and Plates are primarily made from nickel-chromium-cobalt alloys, enhanced with titanium and aluminum. This unique composition delivers outstanding performance at high temperatures and excellent resistance to creep and oxidation. They showcase impressive tensile and yield strength, superior fatigue resistance, and remarkable toughness, even when faced with thermal stress. Thanks to their exceptional mechanical stability, these sheets and plates maintain their properties at elevated temperatures, making them perfect for challenging environments. Their carefully balanced composition and durability ensure reliable performance across a wide array of critical engineering applications.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nimonic 90 Sheets and Plates find extensive use in high-performance industries where top-tier heat and corrosion resistance is crucial. In the aerospace sector, they are utilized in turbine blades, jet engine components, and exhaust systems. Power plants rely on them for gas turbines, heat exchangers, and boiler components due to their ability to handle extreme thermal conditions. They also play a significant role in automotive exhaust valves, chemical processing equipment, and marine engineering. With unparalleled strength and dependability, Nimonic 90 Sheets and Plates deliver exceptional performance in demanding applications.
