Hakan Nickel Alloys is a reliable Turkish manufacturer and supplier of high-quality nickel-copper alloy products such as Monel K500 pipes. They are known for their high standards and accuracy and take great care that every pipe is up to international standards, providing unmatched durability and performance. Their Monel K500 pipes are made to handle harsh environments, with high corrosion resistance and high mechanical strength. With customer satisfaction and reliability being its focus, the company serves numerous industries globally through the supply of heavy-duty piping solutions for severe applications.
Monel K500 tubing is produced from a nickel-copper alloy hardened with additions of aluminum and titanium that have a very important effect on mechanical properties like tensile strength (up to 830 MPa) and hardness over Monel 400. In spite of this improvement in strength, Monel K500 retains good corrosion resistance to sea water, acids, alkalis, and stress corrosion cracking. The alloy has good weldability, toughness, and resistance in severe environments, ideal to be used in harsh industrial applications where both strength and corrosion resistance are critical.
| Specifications | ASTM B 163 ASME SB 163 / ASTM B 165 ASME SB 165 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Size | 15″NB TO 150″NB IN |
| Specialized in | Large Diameter Size |
| Range | 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness. |
| Type | Seamless / ERW / Welded / Fabricated |
| Form | Round, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
| Monel K500 | Ni | C | Al | Mn | Si | Fe | Cu | S | Ti | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| 63.0 min | 0.25 max | 2.3 – 3.15 | 1.5 max | 0.5 max | 05 – 2 | 27.0 – 33.0 | 0.010 max | 0.35 – 0.85 | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 1,60,000 , MPa – 1100 | 20 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Pipes Fittings in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel K500 pipes have found extensive application in marine engineering, aerospace, chemical processing industries, oil and gas, and power generation. Their excellent strength and corrosion resistance allow them to find application in high-pressure piping systems that are subjected to seawater, sour gas, and other aggressive chemicals. Such pipes are also preferred in desalination plants, offshore platforms, and underwater installations where endurance and resistance to stress corrosion cracking are of prime importance. Their consistency in performance in adverse conditions makes Monel K500 pipes a good selection for rigorous fluid transportation and structural uses.
