Hakan Nickel Alloys, a reputable manufacturer and supplier located in Istanbul, Turkey, proudly offers top-notch **Monel 400 Sheets and Plates** that are designed to provide outstanding corrosion resistance, strength, and durability. Produced under rigorous quality control and adhering to international standards, these sheets and plates are perfect for demanding industrial applications. Hakan Nickel Alloys delivers dependable materials that can withstand harsh environments, catering to industries like marine, chemical, oil and gas, and petrochemical. With their exceptional mechanical stability and resistance to aggressive substances, Monel 400 Sheets and Plates guarantee long-lasting performance, making them the go-to choice for high-performance applications in piping, structural, and fluid-handling systems around the globe.
Monel 400 Sheets and Plates are primarily made from a nickel-copper alloy, featuring about 63% nickel and 28–34% copper, along with trace elements of iron, manganese, and carbon. This unique composition offers remarkable resistance to corrosion in seawater, acids, and alkaline conditions. On the mechanical side, they boast high tensile strength, good ductility, toughness, and stability when faced with thermal and mechanical stress. These sheets and plates are also resistant to stress-corrosion cracking and maintain their dimensional stability, making them perfect for applications that demand consistent performance and long-term durability in tough industrial and marine settings.
| Specifications | ASTM / ASME SB 127 |
|---|---|
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel 400 Sheet and Plates in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel 400 Sheets and Plates find extensive use in industries that require robust and corrosion-resistant materials. In marine and offshore settings, they are utilized in seawater piping, pump components, and valve assemblies. The chemical and petrochemical sectors employ them in heat exchangers, reactors, and pipelines that handle corrosive substances. The oil and gas industry counts on them for pressure vessels, drilling equipment, and subsea systems. Additionally, aerospace, industrial engineering, and defense sectors incorporate them into structural components and critical assemblies.
