Hakan Nickel Alloys, Istanbul, Turkey, is a prestigious manufacturer and exporter of high-quality nickel-based alloy components, including **Inconel forged fittings**. Desiring excellence, accuracy, and performance, Hakan Nickel Alloys creates forged fittings that live up to stringent international standards and are designed for applications under rigorous environments. Their Inconel forged fittings possess superior mechanical strength, corrosion resistance, and thermal stability, and are thus best suited for high-temperature and high-pressure applications in numerous industries. The reliability of the company and the satisfaction of customers have established the company as a reliable business partner in international industrial markets.
Inconel forged fittings are produced from high-performance nickel-chromium-based alloys, including Inconel 600, 625, and 718. These alloys exhibit superior oxidation, corrosion, and high-temperature degradation resistance. They have high tensile strength, fatigue strength, and thermal stability over a broad range of temperatures—cryogenic to more than 1000°C. Inconel forged fittings also resist pitting, crevice corrosion, and stress corrosion cracking, particularly in severe environments that include acids, seawater, and high-pressure steam. Their metallurgical stability and toughness qualify them for applications of prime importance.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Forged Fittings in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Inconel forged fittings find extensive application in aerospace, petrochemical, marine, nuclear, and power generation industries. They are traditionally used in high-temperature and high-pressure piping systems, including those used in turbine engines, reactors, heat exchangers, and offshore platforms. They play a vital role in handling corrosive fluids and gases, and they can withstand thermal cycling and mechanical load without losing integrity. Their strength, ruggedness, and resistance to hostile environments make Inconel forged fittings a first choice for critical applications where failure is unacceptable.
