Hakan Nickel Alloys, a top-notch manufacturer and supplier located in Istanbul, Turkey, specializes in high-quality Inconel 617 Stud Bolts that are perfect for demanding industrial applications. These bolts are renowned for their exceptional resistance to high-temperature oxidation, corrosion, and mechanical stress, ensuring that they provide reliable fastening even in the most extreme conditions. Crafted with meticulous attention to quality, the Inconel 617 Stud Bolts from Hakan Nickel Alloys deliver remarkable durability, mechanical strength, and a long service life, making them a go-to choice for industries like aerospace, petrochemical, marine, and power generation.
The Inconel 617 Stud Bolts are primarily made up of nickel (around 52%), chromium (22%), cobalt (12%), and molybdenum (9%), along with trace elements that boost their high-temperature strength and corrosion resistance. On the mechanical side, these bolts boast a tensile strength ranging from 830 to 1000 MPa, along with excellent yield strength and outstanding creep and fatigue resistance. They maintain their toughness, dimensional stability, and reliable performance across a broad temperature spectrum, including both cryogenic and elevated-temperature settings, making them ideal for extreme applications.
Standard ASTM B168, B166 / ASME SB168, SB166
Dimensions ANSI B18.2.1, DIN 931,DIN 933, ISO 4014, ISO 4017,BS 1768, BS1768, IFI 115
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Size M02 to M160
Length 3 mm to 200 mm
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Stud Bolts in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 617 Stud Bolts find extensive use in chemical and petrochemical facilities for securing reactors, heat exchangers, and piping systems that are exposed to high-temperature corrosive fluids. In the aerospace and marine sectors, they are utilized in turbines, jet engines, and high-temperature exhaust systems that demand strong and durable fastenings. Their applications in power generation include boilers, superheaters, and nuclear reactors. Thanks to their excellent corrosion resistance, high-temperature strength, and mechanical reliability, Inconel 617 Stud Bolts are essential for fastening critical components in tough and challenging industrial environments.
