Hakan Nickel Alloys, based in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-quality **Inconel 601 Stud Bolts**. These bolts are specifically designed to thrive in high-temperature and corrosive environments. Known for their remarkable strength, resistance to oxidation, and overall durability, they are perfect for critical industrial applications where safety and reliability are non-negotiable. With a commitment to precision manufacturing and strict adherence to international quality standards, Hakan Nickel Alloys guarantees that their products deliver long-lasting performance and structural integrity. You’ll find their Inconel 601 Stud Bolts in various sectors, including aerospace, chemical processing, power generation, marine, and furnace equipment, providing trustworthy fastening solutions even in the most extreme conditions.
**Inconel 601 Stud Bolts** are made from a nickel-chromium alloy enriched with aluminum, which gives them outstanding resistance to oxidation, carburization, and high-temperature corrosion. They boast high tensile strength, excellent creep and fatigue resistance, and impressive dimensional stability across a broad temperature range. These bolts maintain their toughness and ductility even in harsh service conditions, ensuring reliable mechanical performance in critical applications where both strength and environmental resistance are essential.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find **Inconel 601 Stud Bolts** widely used in industries that require high-performance fastening under severe conditions. In aerospace, they play a crucial role in jet engines, exhaust systems, and turbine assemblies. The power generation sector relies on them for boilers, superheaters, and components in nuclear reactors. In chemical processing, they are essential for reactors, heat exchangers, and high-temperature piping systems. Marine applications include offshore platforms and pipelines exposed to seawater. Their exceptional blend of corrosion resistance, thermal stability, and mechanical strength makes Inconel 601 Stud Bolts vital for ensuring safe, reliable, and long-lasting operations in critical industries.
