Hakan Nickel Alloys, located in Istanbul, Turkey, is a well-respected manufacturer and supplier of high-performance alloy components, including Incoloy Pipe Fittings. These fittings are specifically crafted for use in extremely corrosive and high-temperature settings, providing outstanding resistance and long-lasting reliability. Hakan Nickel Alloys produces Incoloy Pipe Fittings that adhere to international standards, ensuring precision, durability, and compatibility with essential industrial systems. The company caters to various sectors such as chemical processing, power generation, oil and gas, and marine engineering, delivering reliable solutions that meet the challenges of demanding service conditions across global markets.
Incoloy Pipe Fittings are primarily constructed from a variety of nickel-iron-chromium alloys, including grades like Incoloy 800, 825, and others. These alloys typically incorporate elements such as nickel, chromium, molybdenum, and copper, depending on the specific grade, to boost corrosion resistance in both oxidizing and reducing environments. On a mechanical level, Incoloy fittings provide high tensile strength, excellent thermal stability, and resistance to stress corrosion cracking, pitting, and crevice corrosion. They maintain their structural integrity across a wide range of temperatures and under mechanical stress.
Specifications : ASTM B366 / ASME SB366
Size : Seamless Inconel / Incoloy Butt Weld Fittings: 1/2″ – 10″
Welded Inconel / Incoloy Butt Weld Fittings: 1/2″ – 48″
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Thickness : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Types : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Pipe Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Pipe Fittings | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Pipe Fittings in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy Pipe Fittings find extensive use in piping systems that manage aggressive media, high pressure, and elevated temperatures. Common applications include chemical plants, refineries, nuclear and fossil fuel power plants, heat exchangers, offshore oil rigs, and marine environments. These fittings ensure strong, leak-proof connections in systems that transport acids, chlorides, seawater, and other corrosive substances. Their remarkable weldability, formability, and long service life make them a top choice for engineers and plant operators who prioritize reliability and reduced maintenance in harsh operating conditions.
