Hakan Nickel Alloys, based in Istanbul, Turkey, is a reputable manufacturer and supplier of top-notch Incoloy 800/800H/800HT Stud Bolts. Known for their precision and durability, this company caters to a variety of industries that need dependable fasteners for high-temperature and corrosive environments. Their Incoloy 800/800H/800HT Stud Bolts are crafted using cutting-edge manufacturing techniques and rigorous quality control, ensuring they meet the highest standards for dimensional accuracy, mechanical strength, and long-lasting performance. Hakan Nickel Alloys delivers solutions that comply with international standards, making their stud bolts perfect for critical applications in power plants, chemical facilities, refineries, and other demanding industrial environments.
These Incoloy 800/800H/800HT Stud Bolts are primarily made of nickel, iron, and chromium, with trace amounts of carbon, manganese, and silicon to boost their strength and resistance to corrosion. They showcase remarkable stability at high temperatures, impressive tensile strength, and excellent oxidation resistance, making them ideal for extreme conditions. Incoloy 800H is known for its superior creep-rupture strength at elevated temperatures, while Incoloy 800HT offers enhanced resistance to thermal aging. These bolts maintain their structural integrity even under thermal cycling and mechanical stress, ensuring long-term reliability and safety in challenging industrial systems.
| Stud Bolt size | M02 to M33, Custom Sizes |
|---|---|
| Stud Bolts Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard of Stud Bolts | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form of Stud Bolts | Hex, Threading, Square, Round as per Gauge Etc. |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin, etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Popular Types of Stud Bolt | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate of Stud Bolts | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Stud Bolts Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Stud Bolts finishing | Coatings & Finishes : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide, |
| Grade | C | Mn | Si | S | Cr | Fe | Ni |
| Incoloy 800 | 0.1 max | 1.5 max | 1.0 max | 0.015max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Incoloy 800H | 0.05 – 0.1 | 1.5 max | 1.0 max | 0.015 max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Incoloy 800HT | 0.06 – 0.1 | 1.5 max | 1.0 max | 0.015 max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Stud Bolts in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Stud Bolts find extensive use in petrochemical, chemical processing, power generation, and marine applications where high-temperature corrosion resistance is crucial. They are perfect for heat exchangers, pressure vessels, boilers, and piping systems that are exposed to high temperatures and corrosive environments. These bolts create secure and durable connections in essential equipment, preventing leaks and promoting operational efficiency. With their outstanding mechanical properties and resistance to oxidation and thermal stress, they are vital in industries that demand robust fastening solutions for extreme and high-temperature settings.
