Hakan Nickel Alloys, a reputable manufacturer and supplier located in Istanbul, Turkey, specializes in high-quality Incoloy 800/800H/800HT Pipe Fittings. These fittings are specifically designed for high-temperature and corrosive environments. Renowned for their outstanding resistance to oxidation, carburization, and chemical corrosion, they provide secure and long-lasting connections in critical piping systems. Manufactured under strict quality standards, the Incoloy 800/800H/800HT Pipe Fittings from Hakan Nickel Alloys deliver exceptional reliability, precise dimensions, and an extended service life, making them perfect for applications in the chemical, petrochemical, marine, and power generation sectors.
The Incoloy 800/800H/800HT Pipe Fittings are mainly made up of nickel (30–35%), chromium (19–23%), and iron (39–45%), with carefully controlled amounts of titanium and aluminum added to boost creep strength and resistance to high-temperature oxidation. These fittings showcase impressive tensile strength ranging from 485–620 MPa, along with excellent yield strength and remarkable creep and rupture resistance. They maintain toughness, dimensional stability, and corrosion resistance across a broad temperature range, ensuring dependable performance in challenging operating conditions.
Specifications : ASTM B366 / ASME SB366
Size : Seamless Inconel / Incoloy Butt Weld Fittings: 1/2″ – 10″
Welded Inconel / Incoloy Butt Weld Fittings: 1/2″ – 48″
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Thickness : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Types : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Pipe Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Pipe Fittings | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Pipe Fittings in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Pipe Fittings find extensive use in the chemical and petrochemical industries for connecting pipelines, reactors, and heat exchangers that handle aggressive chemicals and high-temperature fluids. In the power generation sector, they are utilized in steam boilers, superheater systems, and heat recovery units. The marine and offshore industries also rely on these fittings in desalination plants and seawater systems, where corrosion resistance and durability are essential. With their combination of mechanical strength, corrosion resistance, and thermal stability, Incoloy 800/800H/800HT Pipe Fittings are vital for creating safe, efficient, and long-lasting piping systems.
