Hakan Nickel Alloys in Istanbul, Turkey makes Hastelloy Forged Fittings, which are strong metal parts shaped by pressing or hammering to connect pipes and tubes. These fittings are very tough and can handle high heat, pressure, and harsh chemicals without cracking or rusting. Hastelloy Forged Fittings are used in chemical plants, power plants, oil and gas industries, ships, and aerospace. Hakan Nickel Alloys ensures every forged fitting is smooth, strong, and reliable. Engineers and workers can use these fittings safely for a long time, providing secure and durable pipe connections in tough industrial conditions.
| Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Forged Fittings in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Forged Fittings are used wherever strong, heat-resistant, and corrosion-resistant pipe connections are needed. Chemical factories use them to join pipes carrying acids, chemicals, and hot liquids safely. Power plants use them in turbines, boilers, and piping systems under high heat and pressure. Oil and gas industries rely on these fittings in pipelines, refineries, and offshore platforms. Ships use them to safely connect pipes exposed to seawater and chemicals. Aerospace industries use them in high-temperature systems. Hastelloy Forged Fittings are chosen because they provide strong, safe, reliable, and long-lasting connections in tough industrial environments.
