Hakan Nickel Alloys, located in Istanbul, Turkey, is a well-respected manufacturer and supplier known for its top-notch Hastelloy C22 Stud Bolts, specifically designed for industries in Da Nang, Vietnam. With a strong focus on creating corrosion-resistant fasteners, the company guarantees products that not only meet international standards but also thrive in challenging environments. Hastelloy C22 Stud Bolts are highly sought after in sectors that demand high strength, durability, and resistance to harsh chemicals. Hakan Nickel Alloys prides itself on precision engineering, prompt delivery, and ensuring customer satisfaction, making it a reliable partner for clients in fields like chemical processing, marine, petrochemical, and environmental engineering.
| Specification | ASTM F468, B574 / ASME SF468, SB574 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C22 Stud Bolts | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy C22 Stud Bolts in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy C22 Stud Bolts are commonly found in chemical processing plants, where they can handle corrosive chemicals, acids, and oxidizing agents with ease. They’re also utilized in the marine industry for equipment that faces seawater and tough environments, ensuring they last longer. In the petrochemical field, these bolts are vital for secure fastening in high-pressure and high-temperature systems. Moreover, they are used in power generation, pollution control, and pharmaceutical industries, where reliability and resistance to corrosive substances are key. Their versatility truly makes them an essential choice for demanding engineering applications.
