Home > Duplex Steel > Duplex Steel 2205 Flanges
Hakan Nickel Alloys, located in Istanbul, Turkey, is a well-respected manufacturer and supplier of Duplex Steel 2205 Flanges, known for delivering top-notch products tailored for tough industrial applications. These flanges are crafted from a duplex stainless steel alloy that merges outstanding strength with exceptional corrosion resistance, making them perfect for harsh environments. Thanks to precision manufacturing, cutting-edge technology, and a commitment to international standards, Hakan Nickel Alloys guarantees reliable performance and durability. The company caters to various sectors, including petrochemical, offshore, marine, and power generation, providing Duplex Steel 2205 Flanges that ensure long-lasting performance, structural integrity, and safety in critical piping and pressure systems around the globe.
| Specifications | Duplex 2205 |
|---|---|
| Duplex 2205 Flanges Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges. |
| ASME B16.5 Duplex 2205 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Duplex 2205 Flange Standard DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| Duplex 2205 Flange Standard ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Duplex 2205 Flange Standard UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Duplex 2205 Flange Standard EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Duplex 2205 Flange Standard JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Most common types of Duplex 2205 Flanges |
|
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, , Groove |
| Duplex 2205 Pipe Flanges Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production technique |
|
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations Duplex 2205 Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of |
|
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Duplex 2205 2205 Flanges Standard | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc.
BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange
|
| Key markets and industries for Duplex 2205 Flanges |
|
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Istanbul, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, etc |
| Duplex 2205 Flanges Application |
|
| The Chemical Composition of 2205 Duplex Steel Flanges, % | |
|---|---|
| Sulfur | ≤0.02 |
| Chromium | 21.0-23.0 |
| Nickel | 4.5-6.5 |
| Carbon | ≤0.03 |
| Manganese | ≤2.00 |
| Silicon | ≤1.00 |
| Phosphate | ≤0.03 |
| Molybdenum | 2.5-3.5 |
| Nitrogen | 0.08-0.2 |
| Gr. | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| Duplex Steel S32205 Flanges | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel 2205 Flanges in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel 2205 Flanges find a wide range of applications across industries where strength and corrosion resistance are paramount. They’re commonly used in chemical processing plants, oil and gas pipelines, offshore platforms, desalination facilities, and marine engineering projects. Additionally, these flanges are utilized in high-pressure and high-temperature piping systems, heat exchangers, and pressure vessels that come into contact with chloride-containing media. Their ability to resist pitting, crevice, and stress corrosion makes them perfect for long-term use in challenging environments. Duplex Steel 2205 Flanges provide reliability, safety, and operational efficiency in demanding conditions.
