Hakan Nickel Alloys, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of premium metal alloy products, with a special focus on Copper Nickel Wire. With years of experience under their belt and a strong dedication to quality, this company caters to a variety of industrial sectors both at home and abroad. Renowned for their precision in manufacturing, rigorous quality control, and a customer-centric approach, Hakan Nickel Alloys ensures that their products meet international standards. Their Copper Nickel Wire is particularly sought after for its exceptional corrosion resistance, outstanding conductivity, and long-lasting durability, making them a reliable partner for clients in marine, power generation, and industrial engineering fields.
Typically, Copper Nickel Wire is made up of 90% copper and 10% nickel, though other ratios like 70/30 or 75/25 are also available based on specific application requirements. The inclusion of nickel significantly boosts the alloy’s resistance to corrosion, especially in marine and brackish water settings. It boasts impressive mechanical properties, including tensile strength ranging from 300 to 500 MPa, good ductility, and high thermal stability. Additionally, the wire features low electrical resistivity and remarkable resistance to biofouling, stress corrosion cracking, and hydrogen embrittlement, making it perfect for challenging industrial and marine uses.
| Specifications | ASTM B206, ASME SB206 | |
|---|---|---|
| Copper Nickel Wire Grades | 90/10 Copper Nickel Wire, 70/30 Copper Nickel Wire (Cuni 90/10 & Cuni 70/30) | |
| Copper Nickel Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Copper Nickel Wire Length | 100 mm TO 6000 mm, customizable | |
| Copper Nickel Wire Diameter | 10 mm To 100 mm or as per client requirement | |
| Copper Nickel Wire Main Types |
| |
| Copper Nickel Wire Density | 8.89 g/cm3 | |
| 580-750 | |
| as standard | |
| 28-30 | |
| Surface | Polished bright, Smooth | |
| Copper Nickel Wire Technique | Cold Rolled, hot rolled | |
| Copper Nickel Wire Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Copper Nickel welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| Copper Nickel wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including: |
|
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70-30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 2260 F | 50000 psi | 20000 psi | 30 % |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Wire in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Wire finds its way into numerous industries thanks to its excellent corrosion resistance and mechanical strength. In the marine industry, it plays a crucial role in seawater piping, heat exchangers, and condenser tubing. It’s also utilized in shipbuilding, offshore platforms, and desalination facilities. In the realm of electrical and electronics, its stable electrical resistance and thermal characteristics make it ideal for thermocouples and precision resistors. Furthermore, Copper Nickel Wire is employed in automotive components, power generation systems, and industrial instrumentation. Its superb workability and long-lasting durability make it a go-to choice for engineers and manufacturers around the globe.
