Hakan Nickel Alloys, located in Istanbul, Turkey, has made a name for itself as a top-notch manufacturer and supplier of high-quality Copper Nickel 70/30 pipes. With a solid reputation for providing corrosion-resistant piping solutions, the company serves a variety of sectors, including marine, offshore, power generation, and industrial markets worldwide. Hakan Nickel Alloys produces Copper Nickel pipes that adhere to international standards and specifications, ensuring they perform reliably even in the harshest and most corrosive environments. Renowned for their precision, durability, and outstanding service, the company is committed to supporting customers with prompt delivery, technical assistance, and customized pipe solutions tailored to meet specific application needs.
Copper Nickel 70/30 pipes are made up of roughly 70% copper and 30% nickel, with small amounts of iron and manganese added to enhance their mechanical strength and corrosion resistance. This alloy is known for its exceptional resistance to seawater corrosion, erosion, and stress corrosion cracking. Typically, these pipes exhibit tensile strengths between 310 and 355 MPa, a yield strength of around 125 MPa, and an elongation of about 30%. These impressive properties make Copper Nickel 70/30 pipes ideal for high-pressure and high-temperature environments, ensuring long-term reliability in critical systems.
| ASTM Specification | ASTM B466/ ASME SB466, ASTM B467/ ASME SB467, ASTM B608 |
|---|---|
| Standard | GB, DTD, ASME, AISI, ASTM, TOCT, JIS, NF, SAE, DIN, AMS, DS, EN |
| Size of Seamless Pipe | Wall thickness.: 0.05- 20 milimeter, 4 – 219 milimeter |
| Size of Welded Pipe | 5.0 to 1219.02 milimeter |
| size of EFW Pipe | 5.0 to 1219.02 milimeter |
| Seamless Tube Size | 3.35 milimeter To 101.6 milimeter OD |
| Welded Tube Size | 6.35 milimeter To 152 milimeter OD |
| Bwg & Swg | 18 Swg., 14 20 Swg., Swg. Swg., 12 16 Swg., 10 Swg. |
| Tubing wall thickness | 0.020″ –0.220″, (custom wall thicknesses available) |
| Pipe Schedule | SCH20, XS, STD, XXS, SCH60, SCH140, SCH80, SCH80, SCH5, SCH40S, SCH40, SCH120, SCH10S, SCH10, SCH30, SCH160 |
| Length | Standard & Cut length , Single Random, Double Random Pipe |
| Finish | AP (Annealed & Pickled), BA (Bright & Annealed), NO.1, 2B, Polished, MF, HL, NO.4, Mirror finish, BA, 8K etc |
| End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Form | Hydraulic, Rectangular, Coiled, Square, Hollow, Round, Straight Pipes/tubes, “U” Shape, Pan Cake Coils, Boiler, LSAWetc. |
| Application | Dairy Pipe, Oil Pipe/tube, Gas Pipe/tube, Fluid Pipe/tube, Boiler Tube, Heat exchanger Tube |
| Type | Seamless /ERW/ EFW / Welded / Fabricated /CDW /DOM/CEW Copper Nickel 70/30 Pipe |
| Cu | Pb | Mn | Fe | Zn | Ni | |
|---|---|---|---|---|---|---|
| MIN | 65.000 | – | – | 0.400 | – | 29.000 |
| MAX | 70.000 | 0.500 | 1.000 | 1.000 | 1.000 | 33.000 |
| Yield Strength 0.2% Proof (MPa) |
Yield Strength 0.2% Proof (MPa) |
Tensile strength (MPa) |
Elongation (% in 50mm) |
Hardness (HRB) |
|---|---|---|---|---|
| MIN | 88 | 372 | 45.00 | |
| MAX | 483 | 517 | 51 |
| Density | kg/dm³ | 8.95 |
|---|---|---|
| Melting Range | °C | 1170-1240 |
| Specific Heat | J/kg °K | 377 |
| Thermal Conductivity | W/m°K | 29 |
| Coeff. of Linear Expansion 10-300°C” | 10-6/°K | 16 |
| Electrical Resistivity | microhm. cm | 34 |
| Modulus of Elasticity | GPa | 152 |
| Modulus of Rigidity | GPa | 56 |
At Hakan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Pipes in Istanbul, Turkey, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Turkey, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In the marine and offshore industries, Copper Nickel 70/30 pipes are commonly used for seawater cooling, fire-fighting systems, ballast systems, and bilge piping, thanks to their excellent resistance to corrosion and biofouling. They also find applications in desalination plants, heat exchangers, condensers, and chemical processing units, where exposure to aggressive fluids is a regular occurrence. In power generation, these pipes are utilized in condenser and auxiliary systems. Their durability, low maintenance requirements, and ability to endure extreme conditions make them a go-to choice for demanding and corrosive applications.
